Pellet Mill Machine LD720
Vertical Ring Die Pellet Machine is a new biomass fuel production machinery by processing scrap from forest and agricultural waste like eucalyptus, pine ,birch, poplar, fruit and agricultural straw, bamboo. Compared with the old machine, it absorbed the essence of horizontal ring die and flat die pellet machine ,solved the insufficient pressure ,die crack problems of horizontal ring die pellet machine, and overcame the small capacity ,high failure rate of flat die pellet machine.
It adopt the large modulus hardened surface helical gearbox , main shaft reinforcement , Power output is strong , Good stability , Low failure rate ,Low production cost, so it is the first choice machinery for biomass energy industry .
|Pellet diameter||6/8/10 mm||6/8/10 mm||6/8/10 mm||6/8/10 mm|
|Dust collecting system||Cyclone, dust collector,fan blower systemCyclone, dust collector,fan blower system|
|Deceleration model||Gear level 3 drive|
|Roller type||Sealed roller without lock|
|Die material||Alloy steel or Stainless steel|
|Die heat treatment hardness||HRC55-60|
|Die lifetime||800-1000 Hours(alloy steel) |
1000-1500 Hours (stainless steel)
Macreat machinery Co.,ltd specializes in manufacturing pellet machines and other machines useful in the whole pellet line. And Macreat is the subsidiary factory of Yantai Lida woodworking machinery Co.,ltd, which has over 50 years' history of manufacturing all kinds of China-made woodworking machinery since 1960, especially for the MQ ML series combined woodworking machine, it has the extremely important guiding function in the circle.
During the past few years, with the development of the company and the staffs, we also expanded our production to energy equipment industry. Now our main products cover biomass energy equipment ,feed processing equipment ,organic ferlizer production equipment three major series .With CE certificate and ISO9001 quality guaranteed and our consistant efforts ,our products have been exported to more than 30 countries in the world and enjoy fairly good reputation especially in Malaysia ,Vietnam ,Thailand ,Indonesia and other countries .
Thanks for our top quality, excellent service and competitive price, thanks for all the support from our customers, we achieved advantages below :
* More than 300 employees, 56 technicians, covering an area of 35000 square meters.
* ISO9001:2000, CE certified, 15 national patents.
* One-stop service, meet needs of the customers from individuals to international companies.
* OEM service accepted.
* Inquiries are typically answered within 24 hours.
* After sale Service: experienced and knowledgeable team of technical support.
* Annual turnover: USD 10 million.
1.Will you send engineers to install the plant?
Our machines are well designed and easy installation. Engineers will be send when clients meet problems they can't solve by themselves.
2.How about the quality of your products?
The materials we used purchase from stable supplier and our quality controller guarantee each process no-mistake. Most of our clients' feedback said that LIDA has good quality control and the machine have good performance.
3.Do you provide after-sale service?
We believe that after-sale service is one of the most important section in whole sales process. So, our team will treat every client by a high standard.What's the lifetime of the wearing parts?. If you have any question after purchase, we will solve them.
4.What about the size of the final wood pellet product?
The pellets diameter between 4 to 12mm.Our standard ring die diameter are 6,8,10mm. We can also offer customization for each client.
5.What's the lifetime of the wearing parts?
It depends on the materials you use. The fewer impurities, the longer wearing parts will use. If you pay more attention to maintenance, it will make lifetime longer.
1. 24 hour technical support by email or calling
2. User-friendly English manual for machine using and maintaining
We trust that our experience and intimate knowledge of this line will entitle us to your confidence.
The more you know us, the more you trust us!
